AKW Braddan Surface Mounted SHWR Tray, w/ Upward Pumped Waste - Choice of Size, OPT Ramps

The AKW Braddan shower tray is available in a large range of sizes and offers easy installation. The tray is 40mm thick and can be installed in a corner or alcove and is suitable for unbreachable floors because of the upward pumped waste, surface-mounted.

The trays are unhanded with a centre waste outlet the upward pumped waste is included.

The 1800mm long trays are supplied with a ‘trim to length’ kit, allowing up to 300mm to be cut off. Note: trimmed trays are only suitable for alcove installations, not corners.

Create the perfect shower room with the addition of a compatible AKW shower enclosure or door set from the Larenco, Level Best, Silverdale® and Standard Screens ranges.

Key benefits:

• Suitable for use on unbreachable floors
• Can be installed as a surface-mounted step-in shower enclosure (order shower doors or screen separately)
• The tray creates a visually defined showering area useful for those with visual impairment
• Slip resistance textured surface a safer showering experience for the user
• Excellent water drainage with a 35mm fall inside the tray
• 40mm thick multi-purpose tray
• Integral added strength for extra peace of mind
• No under tray foaming is needed for quick and easy installation
• Weight limit: 30 stone/190kg
• Non-handed shower trays for both left or right-handed installations
• Upward pumped waste included
• 1800mm trays can be cut down to 1500mm and supplied with a trim to length kit
• Three separate tiling upstands supplied. Ensures a watertight seal between tray and tiles and secure fitting of tray
• Pipe duct kits available to avoid the re-routing of existing pipework (order separately)
• Optional ramps: 20mm and 40mm straight and corner ramp kits are available - Provides easy access for semi-recessed and surface mounted installations

Waste:

• Upward pumped waste included

Technical details:

• Tray height: 40mm
• Material composition:
• - GRP (Glass-reinforced plastic) all trays except:
• - SMC (sheet moulded compound) 1200x700; 1200x820; 1300x700; 1420x700; 1700x700 & 1800x700mm
• Weight limit: 30 stone/190kg
• Fall to Waste: 35mm
• Supplied with Pumped upward waste (pump not included)
• To be used in conjunction with a AKW Digi-pump shower waste pump (not included)
• Screen Compatibility: Larenco, Level Best, Silverdale® and Standard Screens

Optional - Aluminium Ramp Kits:

• Product Code: 25000 - 20mm Straight Ramp (length 1800mm)
• Product Code: 25001 - 20mm Corner Ramp (for 900x900mm tray)
• Product Code: 25002 - 40mm Straight Ramp (length 1800mm)
• Product Code: 25003 - 40mm Corner Ramp (for 900x900mm tray)
• Product Code: 25012 - 20 or 40mm Corners Made-to-Measure (Order separately)

Warranty:

• Lifetime Warranty (please refer to AKW’s terms and conditions)

Manufacturer Product Codes:

• Tray with Upward Pump Waste code: 16523, 16471, 16473, 16083, 16529, 16168, 16197, 16361, 16090, 16175, 16135, 16521, 16100, 16141, 16082, 16109, 16150, 16496, 16532, 16443, 16121, 16129, 16161, 16120
