AKW Mullen Surface or Level Access, Corner Shower - Choice of Size & Waste

The AKW Mullen corner shower tray is 27mm thick tray, range of sizes and handing. Offset corner 90mm waste hole for quick and easy installation to avoid joists. Choice of GW90 Gravity or the PW90 Pumped wastes with either 15 or 22mm outlets.

Suitable for timber and screed floors, can be surface mounted or recessed for level access. The trays slip resistant textured surface decreases the risks of accidents when using the shower.

Vinyl safety flooring can be clamped to the side of the tray for a leak free joint. Non-slip floor tiles can be used which also requires the Floor Tiling Adaptor kit (Product code: 26259).

The tray is compatible with AKW Standard, Sliding, Glass and Silverdale shower screens, check the image gallery for the compatibility chart.

Key benefits:

• Corner shower tray for level access where the client needs a defined showering area
• Unique vinyl safety flooring integrated clamping strip allows for quick and watertight installations
• Flooring can be fitted after the tray and screen have been installed avoiding unnecessary site visits
• Built in tiling upstands on 2 sides complete the all-round integrity of the water seals
• Suitable for point loading from seats
• Weight limited 190kg / 30 stone
• No under tray foaming is needed
• Corner waste position helps avoid joists
• Ribbed underside eliminating slippage or float during installation
• Watertight seals with the Intergrip® strip for joining vinyl sheet flooring to the tray edge
• Quick draining, with a 25mm fall inside the tray
• Unrivalled strength and stability, using compressed GRP
• Pre-formed fixing holes ensure quick and easy installation
• Slip resistant textured surface
• Floor tiling, wallboard adaptor, and pipe duct kits are available separately to aid any installation

Waste options:

GW90 Low Depth Gravity Waste

• AKW Product Code: 25404
• 50mm water trap depth (seal)
• Built in strainer - Catches hair and debris which can be removed for cleaning
• Unique swivel outlet for quick and easy installation
• Designed for ease of installation and flexibility of fitting
• Depth required under the tray: 60mm
• Manufactured by AKW

90mm Dia. Gravity Waste

• AKW Product Code: 25120
• 50mm Deep Water Trap - Prevents bad odour backflow
• Top access, easy to clean
• Ideal for shower trays on wooden floor installations
• Depth required under the tray: 90mm
• Manufactured by AKW

DW90 Low Height Dry Waste with Domed Cover

• AKW Product Code: 25492-UK
• Meets the performance requirements of British Standards - Ensures product is fully compliant and safe for site requirements
• Useful for solid floors or shallow joists
• Top access, easy to clean
• High flow rate - Accommodates (27l/min with a 15mm head and 1m of pipe)
• Depth required under the tray: 48mm
• Manufactured by AKW

GW90 Metal Topped 90mm Dia. Waste

• AKW Product Code: 25434
• Very compact design, ideal for solid floor or shallow joists installations
• Good seals and location - For easy installation and watertight fitting
• Top access, easy to clean
• Suitable for push fit pipe (with included adaptor) Suitable for push fit pipe (with included adaptor)
• Suitable for push fit pipe (with included adaptor) Suitable for solvent weld pipe (with included adaptor)
• Depth required under the tray: 53mm
• Manufactured by AKW

tdpw90 - 90mm Wide Pumped Waste (15mm JG Outlet)

• AKW Product Code: 25105
• To be used in conjunction with a AKW DigiPump shower waste pump
• Built in strainer - Catches hair and debris which can be removed for cleaning
• Opens for easy cleaning and rodding - Ensuring easy maintenance
• Good seals and location - For easy installation and watertight fitting
• 15mm outlet, John Guest Speedfit Outlet for easy installation
• Depth required under the tray: 36mm
• Manufactured by AKW
• Pump not included

PW90 Pumped Waste (22mm JG Outlet)

• AKW Product Code: 25406
• To be used in conjunction with a AKW DigiPump shower waste pump
• Built in strainer - Catches hair and debris which can be removed for cleaning
• Opens for easy cleaning and rodding - Ensuring easy maintenance
• Good seals and location - For easy installation and watertight fitting
• 22mm outlet, John Guest Speedfit Outlet for easy installation
• Bayonet or screw fit cover
• Baffles reduce noise escaping chambers
• Depth required under the tray: 45mm
• Manufactured by AKW
• Pump not included

Technical details:

• 27mm tray height
• Range of tray sizes, select as required below
• All trays width and depth + 50mm flange
• Screed floors require a 27mm recess for level access
• Can be surface mounted on screed floors, ramps are available for installation above or below vinyl flooring
• Timber floors require plywood (not included) to increase the floor up to the tray height, for complete level access
• Corner 90mm waste outlet hole
• Choice of gravity or pumped wastes
• Unrivalled strength and stability, manufactured from compressed GRP

Warranty:

• Lifetime manufacturer warranty

Manufacturer product codes:

• Tray only code: 26100, 26101L, 26101R, 26072L, 26072R, 26102L, 26102R, 26104L, 26104R
• Tray with Gravity Waste code: 26074, 26106L, 26106R, 26073L, 26073R, 26111L, 26111R, 26110L, 26110R
