AKW Onyx Exclusif White Slate Effect, Level Access Shower Tray - Choice of Size, Wastes, Covers & Ramps

The White slate effect AKW Onyx Exclusif Shower Tray is perfect for a modern level access or step in shower for corner or alcove installations. The concealed centre waste is positioned 200 or 350mm from the head of the tray, depending on the tray length which can be trimmed down to within 150mm of the waste.

This SMS manufactured shower tray is 26mm thick, can be recessed for level access in timber and screed floors or surface mounted for a low level step-in shower tray. Optional Chrome Plated Zinc Die-cast waste cover upgrade and matching ramps for "on floor" surface mounted trays.

Choice of Onyx GW90 Gravity, DW90 low profile dry waste or PW90 22mm Pumped waste.

The trays slate effect offers a slip resistant surface reducing the risks of accidents when using the shower.

The tray is compatible with AKW Larenco, Level Best, Standard, Silverdale and Contour Opulence screens.

Key benefits:

• Modern, contemporary design tray
• White slate finish to improve slip resistance
• Range of tray sizes, select as required below
• Impact resistance and strong
• Lightweight, product weight under 25kg
• Webbed back reinforcements
• White colour finish with matching white waste cover
• High water flow rate (30 l/min)
• Can be recessed or surface mounted
• Weight limited 200kg / 31.5 stone

Technical details:

• Low 26mm profile
• Suitable for ‘on floor’ or ‘in floor installations’
• Concealed center waste 200mm from the tray end up to 1200mm lengths
• Concealed center waste 350mm from the tray end 1400 to 1600mm lengths
• The tray can be trimmed down to within 150mm of the waste
• White slate cover for waste, or upgrade to Chrome Plated Zinc Die-cast
• Optional 1200 x 125 x 26mm ramp for "on floor" installations in Alcoves or Corners
• Manufactured from SMC (Sheet Moulded Compound)
• Choice of gravity, dry or pumped wastes

Waste options:

AKW GW90 Onyx Gravity Waste

• AKW Product Code: 25694
• Prevents bad odour backflow
• Water trap depth (mm): 50
• Flow rate (l/m): 31
• Built in strainer - Catches hair and debris which can be removed for cleaning
• Top access for easy cleaning, rodding and maintenance
• Depth required under the tray: 90mm

DW90 Dry Waste for Onyx Tray

• AKW Product Code: 25696-UK
• Meets the performance requirements of British Standards - Ensures product is fully compliant and safe for site requirements
• Very Compact
• Non return valve - Prevents bad odour backflow
• Will not dry out with sporadic use
• Ensures the trap always retains water aiding in the prevention of bad odour backflow
• Top access for easy cleaning and ensures easy maintenance
• Includes 1 x Pipe Adaptor Kit
• Depth required under the tray: 54mm

AKW PW90 22mm Pumped Waste

• AKW Product Code: 25695
• Two baffles reduce the noise during showering cycle
• Top access for easy cleaning and ensures easy maintenance
• 22mm JG Speedfit Clip outlet
• To be used in conjunction with a AKW Digi-pump shower waste pump (not included)
• Depth required under the tray: 44mm

Onyx Exclusif waste cover options:

• Standard Onyx Exclusif - White
• Upgrade to the Onyx Exclusif - Chrome Plated Zinc Die-cast

Onyx Exclusif White Ramp options:

• The ramp provides access to the low 26mm threshold of the Onyx Exclusif Tray for both wheelchair users and users with limited mobility
• Supports up to 31st (200kg), providing reliable and safe access for wheelchair users
• Manufactured from SMC (Sheet-Moulding Compound) for strength and durability
• White textured slate surface provides a high level of slip resistance
• Matches the appearance of the White Onyx Exclusif Shower Tray
• Lightweight material, ensures a quick and easy installation
• Hidden fixings with screw caps to improve aesthetics
• Can be trimmed on site, requires silicone for installation (not included)
• Note: Fixings screws are not included

Choice of ramp configuration:

• Alcove installation:
• - 1x AKW Code: 12844 - Onyx Exclusif Alcove Ramp (1200mm Ramp and 5x Screw Caps)
• Corner installation:
• - 1x AKW Code: 12843 - Onyx Exclusif Corner Ramp (Quadrant Ramp and 1x Screw Caps)
• - 2x x AKW Code: 12844 - Onyx Exclusif Alcove Ramp (2x 1200mm Ramps and 10x Screw Caps)
• Ramp parts also available separately

Warranty:

• Lifetime manufacturer warranty

Manufacturer product codes:

• 12820WH, 12821WH, 12822WH, 12823WH, 12824WH, 12825WH, 12826WH, 12827WH, 12828WH, 12829WH, 12830WH, 12831WH, 12832WH, 12833WH, 12834WH, 12835WH, 12836WH, 12837WH
