Alca 1.12m Pre-Wall Mounting Frame for Washbasin, 200mm Max. Depth

Alca self-supporting frame for mounting a washbasin with deck mounted taps. Installation depth of up to 200mm maximum, frame width 510mm x 1120mm high, in front of a support wall or within a partition framed wall with a plasterboard finish and a floor thickness of 0-200mm.

Washbasin mounting pitch 80-280mm with a water supply pitch of 65-150mm.

Key benefits:

• Installation depth 200mm max.
• The frame allows the anchoring to a separate sufficiently strong plasterboard partition, in front of the bearing wall
• Can be installed in a partition, in front of the support wall
• Adjustable anchor feet and a spring-lock system, with a range of 0-200mm
• The fitted frame should be covered with a plasterboard panel
• Water supply pitch: 65-150mm
• Frame material: powder-coated metal

Approvals:

• Kiwa Approved

• Washbasin fixings: 2x M10x100 bolts
• Fixation set: 4x screws Ø8×60m, and 4x dowels Ø12
• Covers for the fixing material
• Waste elbow HT 50 with seal
• Connection fittings G1/2" - G1/2"
• Mounting frame
• Max. load: 150kg

Warranty:

• 15 year manufacturer
