AWS Liberation RH Fixed Glass Panel, with Full Height Bi-fold Door - Custom Size (A) Min. 750, Max. 1400mm

Right-hand AWS Liberation 1900mm full-height fixed panel with a bi-fold shower door hung from the side for shower trays. Made to your custom width (A) between 750-1400mm overall, with a full height custom width fixed panel at the wall (min. 250 to max. 400mm) and a bi-fold door with a custom width (min. 500 to max. 1000mm) hung off the fixed panel.

The stylish design adds a touch of elegance and sophistication to the shower tray area.

Manufactured from 6mm thermally toughened safety glass, which is three times stronger than non-tempered glass, that are easy to clean and maintain with a glass anti-limescale coating.

The standard doorknob can be upgraded to a large easy grip ergonomic handle.

The fixed panel and bi-fold door can be used on its own or configured with other AWS Liberation doors and fixed panels to create your own bespoke assisted easy access shower tray enclosure.

Key benefits:

• The glass is anti-limescale, for easier cleaning
• Adjustable wall profile
• Customisable total width (mm): 750-1400
• Provide barrier free access
• 100% recyclable

Components:

• 1x right-hand custom width full-height fixed panel and bi-fold door
• 6mm toughened safety glass
• A satin finish bracket secures the fixed panel to a shower tray
• 1x stainless-steel wall compensator, with chrome cover cap
• 1x stainless-steel 1000mm fixed panel lateral support bar (can be cut to length)
• Includes a doorknob with a satin anodised finish
• Upgrade to an ergonomic handle
• Seals and gaskets prevent water leakage and ensure a watertight seal
• Water deflectors on the lower door panels
• Bi-fold door hung off the fixed panel with 180-degree hinge for the door

Technical details:

• Fixed glass panel height (mm): 1900
• Bi-fold door overall height (mm): 1900
• Wall compensator height (mm): 1920
• Wall profile adjustment for off plumb walls of +15mm to -24mm
• Overall total width (Min./Max. mm): 750 to 1400
• Fixed panel customizable width (Min./Max. mm): 250 to 400
• Bi-fold door customizable width (Min./Max. mm): 500 to 1000
• Please contact us if you require a custom height
• Optional - Frosted toughened glass for increased privacy
• Manufactured and assembled in the UK

Compatibility:

• Can be retro-fitted onto a shower tray with a 40mm flat perimeter
• Wall compensator for shower trays

Accreditations:

• EU Construction Products Regulation (EU) No 305/2011 (CPR)
• BS EN 14428: 2015 + A1: 2018 Shower Enclosures/Doors
• BS EN 12150-1: 2015 + A1: 2019 Glass in building. Thermally toughened soda lime silicate safety glass
• BS EN 12600: 2002 Glass in building. Pendulum test. Impact test method and classification for their flat glass

Warranties:

• Accessories have a two-year warranty
• Lifetime warranty against manufacturing and material defects, excluding normal wear and tear in general domestic applications
• The rubber door seals are not covered by the warranty

Please note:

• This fixed panel and bi-fold shower door is custom made and non-returnable
• The minimum width the "fixed panel" can be manufactured to is 250mm and the maximum overall width is 400mm
• The minimum width the "bi-fold door" can be manufactured to is 500mm and the maximum overall width is 1000mm
• Please ensure accurate dimensions are taken from tile face to tile face or
• The free width of the "flat perimeter" of your shower tray
