Granberg Anodized Alu. Drawer Front 103mm High, for Drawer Boxes - Choice of Size

Granberg drawer front 103mm high x 16mm thick, for the Standard and Push-to-open drawer boxes for the 103mm high compartment frame of the Manulift HA / Baselift HA series and Plusmodules HA of worktop lifting systems and the Centerlift 6490H island lifts.

Aluminium construction, supplied 4mm shorter than the drawer box width.

Key benefits:

• Granberg drawer box fascia front
• Compatible with the Granberg Manulift HA / Baselift HA series and Plusmodules HA of worktop lifts
• Compatible with the Granberg Centerlift 6490H island lifts
• Supplied with colour matched removable end caps
• Anodised Aluminium finish
• If ordered with a drawer box, the drawer front will be factory fitted
• Note: If ordering adjoining facia fronts these should be 4mm shorter to ensure smooth closing of the drawer
• Drawer handle not included

Technical details:

• Height (mm): 103
• Thickness (mm): 16
• Materials: Aluminium body, plastic end caps
• Compatible with Granberg Standard Opening and Push-to-open Drawer Boxes
• Drawer handle not supplied

Warranty:

• 3 year manufacturer warranty

Manufacturer product codes:

• 385H-030-06, 385H-040-06, 385H-050-06, 385H-060-06, 385H-080-06
