Granberg UNILIFT 870 - Kitchen Appliance Lift

The Granberg Unilift 870 is an innovative lifting system raises a base that is designed to have a shelf (optional) to all kitchen appliances to be lifted effortlessly out of cabinets, enabling easier access for both seated and standing users.

Fully electric, it is controlled by a wired hand controller, you can also add the optional wireless remote control.

For installation in a kitchen base unit 400, 500 or 600mm wide, the clever mechanism folds away when not in use allowing the door to close.

Key benefits:

• Height adjustable lifting system for cabinets
• Electric operation
• Raises appliances forwards and upwards from the cabinet in an arc motion
• For cabinets widths of 400, 500 or 600mm
Optional white shelf to match
• Choice of wired hand control or single channel remote control
• Note: A secondary socket outlet is required for the remote-control receiver
• Folds away when not in use, allowing the cabinet door to close

Technical details:

• Height adjustment: Motorised, continuous step-less adjustment 740mm upwards and 500mm outwards from the cabinet
• Speed (mm / sec): 37
• Electrical connection: Plug for 230 V, max. 2.5A
• Max load (kg): 20
• Raised Shelf height (mm): 740
• Unilift base width (mm): 341
• Unilift overall depth (mm): 660
• Unilift base depth (mm): 508
• Shelf parked height (mm): 170
• Materials: Powder-lacquered sheet metal parts (Alu-grey RAL 9006)
• Optional Shelf:
• Shelf dimensions width (mm): 330, 430 or 530
• Shelf dimension depth (mm): 350
• Shelf thickness (mm): 22
• Shelf materials: White laminate with ABS plastic edging

Warranty:

• 5-year manufacturer warranty
• This product comes with a 5-year warranty against manufacturing defects when registered on Granberg's website. Without registration, our standard 3-year warranty applies

Please note:

• Appliances and base unit not included

Manufacturer product codes:

• Complete Unilift Product Codes: 870-040, 870-050, 870-060
• Shelf Product Codes: 891-033, 891-043, 891-053
