Granberg Electric Motorised Washbasin Lift BASICLINE 433-11-20 - Incl. Mixer Tap with 190 mm Lever (TMV3 Approved)

The Granberg Basicline 433 is a wall mounted electric washbasin lift with integrated mirror and LED lighting above, with 190 mm lever tap that is WRAS and TMV3 approved.

Stylish and discreet, the entire system moves to the required height using the corded hand control.

This version includes the 425-011 washbasin with safety system.

Key benefits:

• Complete 250 mm wall mounted height adjustable system with mirror, lighting and washbasin
• Electric operation with corded hand control
• Mirror and lighting move in tandem with the washbasin
• Compact washbasin for children or confined spaces
• Depth of leg room under the washbasin 600 mm
• Sequential TMV3 mixer tap, 190 mm lever (WRAS Approved)
• Plumbing connections are elegantly concealed in the lifting unit
• Includes safety switch - prevents the descent of the lift in the event of an obstruction

Includes:

• 433 Washbasin lift, safety switch, mirror with LED light above
• 425-410 Corded hand control
• 425-011 Porcelain compact junior washbasin with overflow and plug
• 425-331 Flexible drain hose with water trap
• 425-120 Sequential TMV3 mixer tap, 190 mm lever (WRAS Approved)
• Pair of flexible water hoses

Technical details:

• Total width (mm): 620
• Total height when mounted at the recommended height (mm): 1703-1953 (adjustable)
• Height of mirror (mm): 1000
• Total depth from front of washbasin to wall (mm): 600
• Width of washbasin (mm): 600
• Depth of washbasin (mm): 445
• Distance from front edge to tap lever (mm): 175
• Height from top of washbasin to floor (mm): 640-890 (adjustable)
• Speed of operation: 18 mm / sec
• Electrical connection: Mains UK plug for 230 V, max. 1.5A
• IP-class: IPX4
• Wired hand controller, IP65 rated, with support hook
• Lifting force (kg): 100
• Washbasin max. load (kg): 50

Material:

• Back panel: White melamine coated particleboard W899 with 2 mm ABS edging
• Mounting plate: Powder coated Alu-zinc coated steel, white RAL 9010
• Mirror: 1000 x 600 x 4 mm silver-coated float glass with polished edges
• Safety switch and other metal parts: Powder-coated steel sheet

Lighting technical details:

• Lighting: Aluminium/plastic, Colour: Chrome
• LED lighting 12V / 6-8W, 4000K (connected to an external switch)
• Transformer: Primary (in) 220-240 V, Secondary (out) 12V

Warranty:

• 5 year manufacturer warranty
• This product comes with a 5-year warranty against manufacturing defects when registered on Granberg's website. Without registration, our standard 3-year warranty applies
