Granberg Motorised Washbasin Lift BASICLINE 415-15-20 - Incl. Mixer Tap with 190 mm Lever (TMV3 Approved) - White

[mgz_pagebuilder]{"elements":[{"row_type":"full_width_row","content_position":"top","gap_type":"padding","content_align":"center","device_type":"all","background_type":"image","background_style":"auto","background_position":"center-top","parallax_speed":0.5,"mouse_parallax_size":30,"mouse_parallax_speed":10000,"lg_background_type":"image","lg_background_style":"auto","lg_background_position":"center-top","md_background_type":"image","md_background_style":"auto","md_background_position":"center-top","sm_background_type":"image","sm_background_style":"auto","sm_background_position":"center-top","xs_background_type":"image","xs_background_style":"auto","xs_background_position":"center-top","type":"row","id":"ff6jj4w","elements":[{"device_type":"all","background_type":"image","background_style":"auto","background_position":"center-top","parallax_speed":0.5,"mouse_parallax_size":30,"mouse_parallax_speed":10000,"lg_background_type":"image","lg_background_style":"auto","lg_background_position":"center-top","md_background_type":"image","md_background_style":"auto","md_background_position":"center-top","sm_background_type":"image","sm_background_style":"auto","sm_background_position":"center-top","xs_background_type":"image","xs_background_style":"auto","xs_background_position":"center-top","md_size":"","xl_offset_size":"","xl_size":"","lg_offset_size":"","lg_size":"","md_offset_size":"","sm_offset_size":"","sm_size":"","xs_size":"","type":"column","id":"ifcs6um","elements":[{"content":"

The Granberg Basicline 415 is a floor mounted electric washbasin lift the pedestal has a clean white finish. Supplied with a 190 mm lever tap that is WRAS and TMV3 approved.

\n

Stylish and discreet, the entire system moves to the required height using the corded hand control.

\n

This version includes the 425-015 wheelchair accessible washbasin with shallow bowl and integrated gripping slots either side, also ideal for towels and the safety system.

\n

Key benefits:

\n

\n
• Complete height adjustable washbasin system
\n
• 250 mm continuously variable height
\n
• Low level, can be installed beneath a mirror or cabinet
\n
• Electric operation with corded hand control
\n
• Sequential TMV3 mixer tap, 190 mm lever (WRAS Approved)
\n
• Plumbing connections are elegantly concealed in the lifting unit
\n
• Wheelchair accessible washbasin with shallow bowl and integrated gripping slots either side, also ideal for towels
\n
• The washbasin has no overflow (ideal for infection control), slotted waste and no plug
\n
• Depth of leg room under the washbasin 586 mm
\n
• Includes safety switch - the washbasin will stop lowering if it comes into contact with any obstacle or the user's legs
\n

\n

Includes:

\n

\n
• 415 Washbasin lift
\n
• 425-120 Sequential TMV3 mixer tap, 190 mm lever (WRAS Approved)
\n
• 425-410 Corded hand control
\n
• 425-403 Safety switch for Basicline 415 washbasin lift
\n
• 425-015 Solid surface washbasin, with integrated grabrails. Slotted waste only - No overflow or plug
\n
• 425-331 Flexible drain hose with water trap
\n

\n

Technical details:

\n

\n
• Total width (mm): 650
\n
• Total height (mm): 712-962 (adjustable)
\n
• Total depth from front of washbasin to wall (mm): 695
\n
• Width of washbasin (mm): 600
\n
• Depth of washbasin (mm): 550
\n
• Distance from front edge to tap lever (mm): 265
\n
• Height from top of washbasin to floor (mm): 654-904 (adjustable)
\n
• Washbasin centre-to-centre fixings (mm): 280
\n
• Speed of operation: 18 mm / sec
\n
• Lifting force (kg): 100
\n
• Washbasin max. load (kg): 50
\n
• Wired hand control: IP65 rated with support hook
\n
• Electrical connection: Mains UK plug for 230 V / Max. 1.5A
\n
• IP-class: IPX4
\n

\n

Material:

\n

\n
• Back panel: 4 mm compact laminate with sides of anodised aluminium
\n
• Top shelf: 12 mm compact laminate
\n
• Safety switch: Powder-coated sheet steel
\n
• Installation cover: 4 mm compact laminate
\n

\n

Warranty:

\n

\n
• 5 year manufacturer warranty
  This product comes with a 5-year warranty against manufacturing defects when registered on Granberg's website. Without registration, our standard 3-year warranty applies
