Granberg Motorised Washbasin Lift - BASICLINE 433-0 - White

The Granberg Basicline 433-0 is a height adjustable wall bracket for washbasins.

Electrically adjustable by a corded hand controller, and or optional handheld remote control. it is ideal for situations where the height is frequently changed.

The system includes integrated mirror and lighting, which move in tandem with the washbasin.

It should be completed with a washbasin, tap and flexible water hoses (available separately).

Key benefits:

• 250 mm Height adjustable bracket for washbasins
• Electric operation by a corded hand control, optional handheld radio control (Product code: 61386-10)
• Includes mirror and lighting which move in tandem
• Free space below the unit for plumbing connections

Compatible washbasins:

• Max weight (kg): 40
• Max width (mm): 600
• Max depth (mm): 600
• Washbasins centre-to-centre fixings (mm): 280

Includes:

• Granberg BASICLINE 433-0 washbasin lift with mirror and lighting

Optional:

• 425-410 - Cable Hand control
• 61386-10 - Remote Hand control (single channel)
• 425-331 - Flexible drain hose with water trap
• 425-401 - Safety stop switch - prevents the descent of the lift in the event of an obstruction
• Note: If selecting the optional handheld radio control, the safety switch is recommended

Technical details:

• Width (mm): 620
• Depth (mm): 118
• Height adjustment (mm): 250
• Speed (mm / second): 18
• Speed (mm / second): 18
• Electrical connection: Mains UK plug for 230 V, max. 1.5A
• Note: If ordering the optional handheld remote control a double plug socket is required
• IP-class: IPX4
• Wired hand controller, IP65 rated, with support hook
• Lifting force (kg): 100

Material:

• Back panel: White melamine coated particleboard W899 with 2 mm ABS edging
• Mounting plate: Powder coated alu-zinc coated steel, white RAL 9010
• Mirror: 1000 x 600 x 4 mm silver-coated float glass with polished edges
• Optional Safety switch and other metal parts: Powder-coated steel sheet

Lighting technical details:

• Lighting: Aluminium/plastic, Colour: Chrome
• LED lighting 12V / 6-8W, 4000K (connected to an external switch)
• Transformer: Primary (in) 220-240 V, Secondary (out) 12V

Warranty:

• 5 year manufacturer warranty
• This product comes with a 5-year warranty against manufacturing defects when registered on Granberg's website. Without registration, our standard 3-year warranty applies

Order separately:

• Washbasin, tap, 500 mm flexible tap hoses
