Granberg Motorised Washbasin Lift DESIGNLINE 417-0 - White

The Granberg Designline 417-0 is an electric washbasin lift with integrated mirror with LED lighting above.

Stylish and discreet, the entire system moves to the required height using the corded hand control and or optional handheld remote control.

This version comes in a clean white finish that can be completed with a washbasin, tap and flexible feed and waste kit.

Key benefits:

• Tall pedestal 250 mm height adjustable system with mirror and lighting
• White laminate surround with solid oiled oak canopy and 3 x recessed LED spotlights
• Electric operation by a corded hand control, optional handheld radio control (Product code: 61386-10)
• Mirror and lighting move in tandem with the unit
• Plumbing connections can be elegantly concealed in the lifting unit

Includes:

• Granberg Designline 417 washbasin lift with mirror and lighting

Optional:

• 425-410 - Cable Hand control Washbasin lift
• 61386-10 - Remote Hand control (single channel)
• 425-331 - Flexible drain hose with water trap
• 425-401 - Safety switch - prevents the descent of the lift in the event of an obstruction
• Note: If selecting the optional handheld radio control, the safety switch is recommended

Technical details:

• Total width (mm): 715
• Total height (mm): 1770-2020 (250 mm adjustable)
• Depth of pedestal (mm): 120
• Height of mirror (mm): 1000
• Width of mirror (mm): 600
• Speed of operation: 18 mm / sec
• Lifting force (kg): 100
• Wired hand controller, IP65 rated, with support hook
• Electrical connection: Plug to 230 V, max 1.5A
• Note: If ordering the optional handheld remote control a double plug socket is required
• Enclosure IP-class: IPX4

Washbasin:

• Maximum washbasin load (kg): 40
• Maximum width of washbasin (mm): 670
• Maximum depth of washbasin (mm): 600
• Washbasin centre-to-centre fixings (mm): 280

Material:

• Back panel: Plywood coated with high-pressure White laminate (Formica F7949, white)
• Mirror: 1000 x 600 x 4 mm silver-backed float glass with ground edges incl. mirror clips
• Mounting cover: White plastic
• Safety switches and other metal parts: Powder-coated steel sheet

Lighting technical details:

• Lighting: Solid oiled oak with 3 x recessed spotlights (connected to external power switch)
• Spotlights: LED 3W, 3000K
• Transformer: Primary (in) 230V, Secondary (out) 12V

Warranty:

• 5 year manufacturer warranty
• This product comes with a 5-year warranty against manufacturing defects when registered on Granberg's website. Without registration, our standard 3-year warranty applies
