Granberg Wall Mounted Cranked Mini Kitchen Module 6350-ESFS - Left, Choice of Widths 990-1190mm

Granberg’s Mini kitchen Module 6350-ESFSL, a wall mounted hand cranked worktop lift with 300mm of height adjustment. One piece stainless steel worktop with a right hand 2 zone hob cut-out and a left hand single bowl shallow depth insulated kitchen sink with overflow. The insulated sink bowl prevent scalding of users knees/legs.

The worktop lift features a smooth stainless worktop that is ideal for preparing food or as drying area.

Choice of optional Granberg FM Mattsson kitchen monobloc mixer taps, 190mm easy to reach lever with a swivel spout - with or without dishwasher cut-off valve.

The underside of the ESFS stainless steel worktop/drying area is supported by a fully-glued MDF board.

The folding crank handle, prevents removal and theft, that can be ordered left or right hand mounted.

Pre-fitted front facia, the rear cover panels are easy to fit and hide the legs and services.

The modules are manufactured 10mm shorter in width, to allow for a 5mm clearance gap at both ends for safe movement, ideal for the direct replacement of 1000 and 1200mm width cabinets. The module has a reduced depth of 15mm to accommodate splashbacks and wall tiles.

Electric floor standing systems or Manual wall mounted variations are also available.

Key benefits:

• Left hand mini kitchen module with 300mm of hand cranked height adjustment, 730-1030mm above the floor
• Folding crank handle, prevents removal and theft
• The wall mounted legs are concealed by 2x matt white sliding cover panels with 2x dark grey coloured steel end plates
• Tilt able worktop plane for adjustment
• Full extension drawers can be added (except; below the hob) as a factory fitted option - (Contact us if required)
• Range of widths 990 and 1190mm to suit standard kitchen base unit spaces: 1000 and 1200mm
• The modules are 10mm shorter in width to allow for a 5mm gap both sides of the unit for the up/down movement
• Adjustable depth 576-606mm including the Alu. front to suit adjoining cabinets and worktops
• 100mm free space below the foot of each leg for services
• Quick solution, top frame supplied pre-assembled for fast site installation
• White Powder Coated RAL 9003 aluminium facia front with plastic end caps
• ESFS stainless steel worktop with one left hand 120mm deep shallow bowl sink, overflow and flexible waste kit
• Insulated underside of the sink bowl to prevent scalding of users knees/legs
• Customizable cut-out, to suit your 2 - zone electric cooking hob (do not fit gas hobs)
• Optional Granberg FM Mattsson (FMM) kitchen monobloc mixer tap with 190mm easy reach lever and swivel spout that can be adjusted to 60°, 85°, 110°, 360° or fixed
• Pair of flexible Water Hoses 2-pack, 3/8", length 500mm with Tap connectors for FMM taps

Optional choice of tap style:

• - 60210 FMM Inc. dishwasher shut off valve (Not WRAS approved)
• - 60211 FMM Excl. dishwasher shut off valve (Not WRAS approved)
• All components available separately

Mini Kitchen Module 6350-ESFS Left includes:

• Wall mounted Manulift 6350 with 2x legs
• Folding crank handle, prevents removal and theft, right or left hand located - as per the product image
• 2x 12mm matt white melamine cover panels hide service installations under the worktop
• White aluminium front facia
• Smooth stainless steel worktop/drying area with raised perimeter
• Brushed aluminium rear edge trim
• ESFS worktop with one left hand 120mm shallow depth sink bowl, shallow trap, strainer waste and a flexible drain hose
• Optional choice of Granberg FMM Mixer tap with long lever with or without dishwasher cut-off valve, and flexible water hoses
• Right hand customizable cut-out, to suit your electric cooking hob

Recommended accessories:

• Full extension, push-to-open integrated drawers
• Cutlery tray
• Mini cabinet on wheels
• FMM long lever kitchen mixer taps, tap hole cutter and flexible hoses
• 2 Zone cooking hob - Please contact us for prices for Neff and other brands

Technical details:

• Height adjustment: Manually cranked adjustable by 300mm (730 - 1030mm)
• Crank handle inset from left or right-hand side of the worktop end by 235mm
• Folding crank handle, prevents removal and theft
• 1x turn for height adjustment of 10mm
• Max. distributed load / Lifting force: 100kg (220lbs)
• Frame depth: 576 - 606mm from the wall (Incl. front)
• Tilt able worktop plane for adjustment
• Front height: 103mm
• All fittings for assembly supplied wall fixings are not included
• Space to adjoining wall / cabinet side (mm): 5
• Space to wall (for tiles): 15mm
• Tiling: From 700 mm above the floor (alternatively tile down to floor level)
• Worktop frame Material: Aluminium frame
• ESFS sink: Smooth 1mm stainless steel sheet
• Bowl size: 293mm width x 400mm depth x 120mm deep
• Shallow trap, strainer waste and a flexible drain hose

2-zone Hob cut-out (The hob shown in images is not included):

• Inset by 50mm from the right-hand end of worktop
• Pre-cut to your specified dimensions
• Inset from the front by 50mm
• Specify your Width x Depth (mm), as per your hob manufactures installation instructions

Stainless steel worktop:

• Hygienic and wear-resistant drying area
• Smooth 1mm stainless steel sheet with a raised edge perimeter
• The underside of the stainless-steel worktop is supported by a fully glued MDF board
• Brushed aluminium rear edge strip
• Overall thickness of worktop: 30mm

Warranty:

• 3 year manufacturer warranty
• This product comes with a 5-year warranty against manufacturing defects when registered on Granberg's website. Without registration, our standard 3-year warranty applies

Please note:

• Due to the custom nature of this product, it is made-to-order and is therefore non-returnable
• The Tap hole is not pre-drilled
