Inta Infrared Wall Mounted Tubular Tap 170mm Length (9V Battery Box)

This Inta wall mounted tubular infrared tap delivers water without contact with the tap, with a 170mm projection length.

An ideal solution where hygiene is paramount, such as in public toilets and washrooms, where vandal resistance is required.

To avoid reflection problems keep a distance of more than 300mm between the basin and spout, this tap is not suitable for use with reflective sinks i.e. stainless steel.

Key benefits:

• Infrared
• Vandal resistant
• Hygienic
• Water saving
• Programmable flow time
• Self adjusting sensor
• Operating pressure range of 0.5 to 8 bar
• Use with a pressure reducing valve in excess of 8 bar
• Security shut off after 90 seconds
• Requires 6x 1.5V AA batteries (not included)
• Self-opening after last water flow: Every 24 hours
• 6 litre per min flow regulator
• Includes an aerator that allows the water stream direction to be adjusted to prevent water splashing

Technical details:

• Spout length (mm): 170
• Min. Inlet pressure dynamic: 0.5 bar
• Max. Inlet pressure static: 8 bar
• Max. Inlet temperature: 70°C
• Min. Sensor range: 80mm
• Max. Sensor range: 300mm
• Security time: 90 seconds - can be reduced with a *Remote control
• Remote control available separately if required, to adjust detection range and timed flow rate
• Power specification: 9V
• When the battery power is low and about to run out, the red indicator light will blink at a constant rate when the user’s hands are within the sensor range
• The batteries must be replaced within two weeks
• Not suitable for installations, where freezing is likely

Warranty:

• 1 year manufacturer warranty

Note:

• To limit the outlet temperature to 41°C max. use the Intamix Thermostatic Mixing Valve (Product Code 40015CP).
