P12 Pump with Push Fit Fittings (with 1x Flow Switch)

This version of the P12 Pump has push fit fittings only and no shower tray or wet floor waste. It is for use with any electric or mixer shower which will require an extra Flow Switch.

Quiet and maintenance-free, this pump will easily cope with hair, shower gels and small obstructions that would normally cause a blockage.

Key benefits:

• Peristaltic pump design
• Near silent operation
• Safe 24v DC low energy motor, with low running costs
• Control box with built in test facility
• ABS Wall plate with quick release pump bracket, minimises installation time
• Supplied with a 2 metre length of 22mm flexible pipe for improved performance
• Wastewater is pumped through a sealed tube reducing the risk of blockages
• Self-priming up to 500mm
• Pumps up to 12 litres per minute
• Variable speed transformer for precise control
• Easily adjustable run-on timer
• Match the speed of pump to flow of water
• Supplied with 1x P12 Pump Flow Switch (Product Code: 05PP11)
• Maintenance free design
• Not handed for easy and quick installation
• Supplied with push fit pump housing cover
• Manufactured in the UK from parts that are 100% recyclable

Shower compatibility:

• Suitable for electric showers - includes 1x Flow Switch which should be installed in the cold water supply
• Suitable for mixer showers - select if an additional Flow Switch (Product Code: 05PP11) for the hot water supply
• If you are installing a AKW, Redring Selectronic Premier WP, Mira Advance ATL Flex Extra or the Triton Safeguard+. Order alternative 'Link' pump (Product Code: 05PP01-L)

Waste compatibility:

• P12 Pump with push fit fittings
• The pump should be fitted no higher than 350mm from the tray outlet to the underside of the P12 wall plate
• The maximum length of the flexible pipe from the waste to the pump should be no more than 2m
• Can be retrofitted and is compatible with all wastes with a 22mm outlet
• Note: A shower waste is not included

Optional covers:

• Control Box Cover (Product Code: 05PP16)
• 1x Flow Switch Cover (Product Code: 05PP17)
• 2x Flow Switch Cover (Product Code: 05PP17x2)

Technical details:

• Actual pump size (mm): 205 W x 270 H x 180 D
• Pump housing cover size (mm): 210 W x 330 H x 190 D
• Power Consumption 36 Watts intermittent rating
• 2.5 amp Fast blow fuse
• IP65 Enclosure for bathrooms
• Pump complies to BS7671

Warranty:

• 5 year manufacturer warranty (based upon correct installation and appropriate application)
