Purus 7110406T 59mm S-Series Minimax Floor Gully – Horizontal Outlet, 197mm Sq. Tile Frame, SS Drop Grate

S-Series Minimax Purus 1-part gulley has an extra-low profile of 59mm, specifically designed for installation in concrete / screed floors with a tiled floor finish.

Ideal for domestic and commercial wet room floors.

Key benefits:

• Low profile waste, reduces volume of concrete / screed required for the floor
• For independent mounting
• NOOD sprung water trap, prevents foul air escaping. The weight of the water opens the trap
• The NOOD water trap is removable for easy cleaning
• Stainless steel clamping ring, with 6 x retaining screws
• The clamping ring retains the Fabric or Butyl Drain Gasket that should be bonded in place as part of your tanking system

Technical details:

• 215mm overall diameter
• Overall height of 59mm
• Horizontal 50mm outlet with 1½" / (40mm) UK adapter
• Flow rate 28.8 litres/minute (0.48 litres/second)
• The gully must be installed horizontally
• Waste material: PP gully with ABS adapter
• Purus grate: Load class K3 (300kg)
• Tiled floors - Purus Tile frame 197x197mm, 6mm high. Stainless steel drop design grate (Product Code: 7138376)

Installation Guidance:

• The minimum gradient should be 1:150 to ensure the flow of water to the floor trap and no more than 1:50 to reduce the risk of slipping
• A nominal 2% falls is usually used
• Only use a fine and hardened concrete around the gully
• The gully must be installed horizontally. It is designed only to be installed level with the surrounding floor
• Tiled flooring - The clamping ring retains the Fabric or Butyl Drain Gasket that should be bonded in place as part of your tanking system, see PDF installation instructions
