Royde & Tucker Double Action Pivot Door Set, 80kg Floor Mounted Lower Pivot Bracket - Satin SS

This pivot hinge set from Royde & Tucker allows doors to swing in either direction.

Constructed from stainless steel, the sets are British made to ensure quality.

Key benefits:

• Allows doors to swing in either direction
• Door plates radii R12.5 for easier preparation
• Bottom bracket is floor mounted and doesn’t protrude beyond the doors face
• Top and bottom plates have HI-LOAD maintenance free oil impregnated bronze bearings
• Suitable for FD30 and FD60 doors, to BS 476 for both single and double door applications
• Maintenance free - 25 year manufacturer guarantee
• Grade 304 stainless steel
• Satin finish

Technical details:

• Minimum door thickness 44mm
• Medium duty for internal doors weighing up to 80kg
• Maximum door width 1100mm
• For 44mm non Fire Rated doors an R9 radius is required on the pivot edge with a 4mm door and frame gap
• For 44mm thick Fire doors an R15 radius is required on the pivot edge as only a 3mm gap is permitted between the door and frame
• For 54mm thick Fire doors an R20 radius is required on the pivot edge as only a 3.5mm gap is permitted between the door and frame

Parts supplied:

• 2x Door plates
• 1x Top frame bracket
• 1x Bottom floor pivot bracket (38mm Sq.)
• 10x 1-1/4" x No. 10 Woodscrews
• 1x Allen Key for top frame bracket adjustment
• Installation Instructions

Recommended accessories:

• Emergency release door stop - prevents pivot swing except in cases of emergency
• Brush strips - it is recommended that both lock and hinge stiles are brush stripped for privacy
