Union Touch Clean Disabled Door Facility Furniture, 150mm Lever - Non-handed

With a large 150mm length satin aluminium lever, this door lock set is designed for use on disabled toilets to suit inward or outward opening swing doors or sliding doors.

Application:

• Non-handed so suitable for left and right handed doors
• Designed for toilet / bathroom doors where ease of operation is desired
• Suitable for hinged and sliding doors
• Suitable doors between 20 to 44mm thick
• Surface mounted
• Bolt-through fixing - can be fitted directly to cubicle or flush panel door
• Exterior handle pull may be fitted at 90°, 180°, 270° or 360°

Specification:

• Supplied with large lever handle, indicator with emergency release, angle strike, staple, bolt through fixings
• AS finish with Touch Clean anti-bacterial coating
• Material: Aluminium with black plastic moulded end caps
• Lever mechanism
• Locking bolt connected directly to lever handle at 90° to facilitate direction change
• Vertical position of lever handle bolts door that can be seen by occupant
• Lever handle travel limited to 30° by screw through centre of backplate - can be increased to 90° by removing screw
• Red and white occupancy signal
• Coin operated emergency release
• Lever length (mm): 150
• Handle Projection (mm): 77
• Plate Projection (mm): 44
• Bolt Length (mm): 41
• Minimum Door thickness (mm): 20
• Maximum Door thickness (mm): 44

Finish:

• Anodised silver
• Touch clean anti-bacterial coating

Standards:

• Assists in fulfilling duties under the Equality Act
• Satisfies recommendations of BS8300 and Approved Document M (ADM)
