Welcome Ramp Kit A, Choice of 120 to 480cm Ramp Lengths, STD Ht. 33cm - 1x Dbl Handrail, 4x Colours

Welcome modular wheelchair access ramp system for domestic use with a double handrail available in 4x colour combinations, that can be located either side of the ramp.

Available in a range for lengths 120cm (4ft) to 480cm (16ft).

This system offers fast assembly, by one person and can be easily transported, dismantled and re-assembled and re-used as required. Offering huge benefits over traditional concrete ramps.

Suitable for a minimum step height 12.5cm (5”) to 33cm (13”) that can be increased to a maximum height of 50cm (20”) with Leg Extensions (Product Code: WLX).

Longer ramps are ideal for higher levels. For outward opening doors and or if a rest area is required, ramp kits with platforms are also available.

Key benefits:

• The ramp is fully self-supporting making the system ideal for uPVC door thresholds
• Extremely durable construction and finish, designed for outdoor use
• Easily modified, adapted and reused
• Fast one-person install the heaviest component is 16kg
• The Gripdeck wearing surface is friendly to pets, high heels and has a superb grip when wet
• Built to last, the system has a huge 400kg capacity
• The handrails are pre-galvanised steel with a powder coated finish that is durable yet ‘warm to the touch’
• The height adjustable legs can be adjusted to suit ground variations and a range of step heights
• Materials: Aluminium and galvanised steel
• Designed, manufactured and stocked in the UK for delivery in 1 to 3 days depending on your Postcode

Choice of 4x handrail colour combinations:

• Original Graphite: Universally appealing soft dark grey - Posts and upper rail
• Garden Green: A traditional deep green, perfect for garden environments - Posts and upper rail
• Heritage Brown: A dark, rich brown to complement traditional and heritage buildings - Posts and upper rail
• Safety Yellow: A rich yellow, perfect for visual safety needs
• Safety Yellow horizontal rail: Posts in Original Graphite
• All rails have Black plastic end caps and Black straps securing the horizontal rail
• Colour matched Bowends also available for the ends of the Double handrails (Product Code: WRBE) order separately

Technical specification:

• Range of lengths: 120cm (4ft) to 480cm (16ft)
• Internal ramp width - 90cm (35”)
• External ramp width - 100cm (39.4”)
• Kerb height - 8cm (3”)
• Mid rail height - 60cm (24”)
Upper rail height - 90cm (35”)
• Ramp system - Minimum installed height 12.5cm (5”)
• Ramp system - Maximum installed height 33cm (13”)
• Leg Extensions (Product Code: WLX) order separately in pairs - Maximum installed height 50cm (20”)

Warranty:

• 10-year Design life

Manufacturer product codes:

• WRA12-D, WRA18-D, WRA24-D, WRA30-D, WRA36-D, WRA42-D, WRA48-D
