Welcome Ramp Kit A, Choice of 120 to 480cm Ramp Lengths, STD Ht. 33cm - 2x Single Handrails, 4x Colours

Welcome modular wheelchair access ramp system for domestic use with two single handrails available in 4x colour combinations, located on both sides of the ramp.

Available in a range for lengths 120cm (4ft) to 480cm (16ft).

This system offers fast assembly, by one person and can be easily transported, dismantled and re-assembled and re-used as required. Offering huge benefits over traditional concrete ramps.

Suitable for a minimum step height 12.5cm (5”) to 33cm (13”) that can be increased to a maximum height of 50cm (20”) with Leg Extensions (Product Code: WLX).

Longer ramps are ideal for higher levels. For outward opening doors and or if a rest area is required, ramp kits with platforms are also available.

Key benefits:

• The ramp is fully self-supporting making the system ideal for uPVC door thresholds
• Extremely durable construction and finish, designed for outdoor use
• Easily modified, adapted and reused
• Fast one-person install the heaviest component is 16kg
• The Gripdeck wearing surface is friendly to pets, high heels and has a superb grip when wet
• Built to last, the system has a huge 400kg capacity
• The handrails are pre-galvanised steel with a powder coated finish that is durable yet ‘warm to the touch’
• The height adjustable legs can be adjusted to suit ground variations and a range of step heights
• Materials: Aluminium and galvanised steel
• Designed, manufactured and stocked in the UK for delivery in 1 to 3 days depending on your Postcode

Choice of 4x handrail colour combinations:

• Original Graphite: Universally appealing soft dark grey - Posts and upper rail
• Garden Green: A traditional deep green, perfect for garden environments - Posts and upper rail
• Heritage Brown: A dark, rich brown to complement traditional and heritage buildings - Posts and upper rail
• Safety Yellow: A rich yellow, perfect for visual safety needs
• Safety Yellow horizontal rail: Posts in Original Graphite
• All rails have Black plastic end caps and Black straps securing the horizontal rail

Technical specification:

• Range of lengths: 120cm (4ft) to 480cm (16ft)
• Internal ramp width - 90cm (35”)
• External ramp width - 110cm (43”)
• Kerb height - 8cm (3”)
• Upper rail Height - 90cm (35”)
• Ramp system - Minimum installed height 12.5cm (5”)
• Ramp system - Maximum installed height 33cm (13”)
• Leg Extensions (Product Code: WLX) order separately in pairs - Maximum installed height 50cm (20”)

Warranty:

• 10-year Design life

Manufacturer product codes:

• WRA12-C, WRA18-C, WRA24-C, WRA30-C, WRA36-C, WRA42-C, WRA48-C
